Onkyo TX-SR393 DAB

Name: Onkyo TX-SR393 DAB
Brand: Onkyo
SKU: TXSR393DABBMMP
Price: 1799.0 RON
Availability: InStock

Receiver AV 5.2, cu Dolby Atmos®

Onkyo TX-SR393 DAB

Receiver AV 5.2, cu Dolby Atmos®

Product form

1.799 lei 3.099 lei Resigilate: 1.699 lei

Întreabă când revine

Free pickup in our shop(s)

Installment payment options

6 installments · Card Avantaj
6 installments · Banca Transilvania
6 installments · Garanti Bank
12 installments · Raiffeisen Bank (in showroom)

Specifications

5.2 cannels
80 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2-ch driven, FTC)
Powered Zone 2
Zone B Line OUT
Dolby Atmos Height Virtualizer DTS Virtual:X
Calibrare sistem: AccuEQ Room Acoustic Calibration with AccuReflex
H.C.P.S. (High Current Power Supply)
Impedanta boxe: 4 - 16 ohm
Analog Audio IN: 3, Optic IN, Coaxial IN, USB Input, HDMI 4 IN / 1 Video OUT
Bluetooth 4.2, Profile: A2DP 1.3, AVRCP 1.5
Tunner FM si Radio DAB

SKU: TXSR393DABBMMP

30 de zile perioada de retur
Garantie luni
Free shipping for orders over 300 RON in Romania
Livrare prin curier sau ridicare din showroom Bucuresti

Resigilate

Default Title 1.799 lei1.699 leieconomisești 100 lei

Documente utile

Fișă de produs Onkyo TX-SR393 (5.2-Channel A/V Receiver)PDF, în limba engleză · publicat de Onkyo Corporation (2019 New Product Release, host oficial assets.onkyo-av.com) · varianta US, echivalentă funcțional cu TX-SR393DAB (UK/EU adaugă doar tuner DAB)

SKUs: TXSR393DABBMMP

Ready for 4K Entertainment

Enjoy support for HDR (High Dynamic Range) video including HDR10, HLG, Dolby Vision^®, and BT.2020. The 4:4:4 color space is also supported. Six HDMI inputs, ARC-ready MAIN OUT, and SUB OUT pass 4K/60p and HDR video from player to compatible TV and projector and all terminals are HDCP 2.2 compliant.

Smooth and Easy Bluetooth Streaming

Whatever audio is playing on your phone, tablet, or PC app can be streamed to the receiver with Bluetooth wireless technology. Once the receiver has paired with and remembered your device, it will start playback automatically whenever it detects an incoming Bluetooth audio stream.

Dolby Atmos® and DTS:X® – Setting Sound Free

Dolby Atmos^® and DTS:X^® formats allow engineers to map sound anywhere in 3D space, effects moving from speaker to speaker all around the room and wrapping your audience in the latest films and games. You can also enjoy your 3D speaker layout with classic titles. Dolby Surround^® and DTS^® Neural:X find overhead cues in legacy soundtracks and upmix for awesome spatial realism.

Dolby Atmos Height Virtualizer

When playing any Dolby^® format, engaging Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without employing additional surround or height speakers.

Technical Specifications

AMPLIFIER
# Channels: 5.2
Power Watts/Ch (8 Ohms 20-20kHz, 2 Channels Driven, FTC): 80 Watts, 0.08% THD
Power Watts/Ch (6 Ohms 1kHz, 1 Channel Driven, FTC): 155 Watts, 10% THD
H.C.P.S. (High Current Power Supply)
Certified 4 Ohms Performance
Discrete Output Stage Circuitry
All Channels: 80 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC) 155 W/Ch (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)
THD+N (Total Harmonic Distortion + Noise): 0.06% (20 Hz–20 kHz, 8 Ohms, 1 Channel Driven, 50 W)
Input Sensitivity and Impedance: 200 mV / 47k Ohms (Line)
Frequency Response: 10 Hz–100 kHz /+ 1 dB, -3 dB (Direct Mode)
Tone Control: ±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio: 109 dB (Line, IHF-A)
Speaker Impedance: 4 ohms–16 ohms

PROCESSING FEATURES
Dolby Atmos
32-Bit Digital Signal Processing Engine
Dolby Atmos Height Virtualizer
Dolby Surround® upmixing
Dolby Decoder: Dolby Atmos, Dolby True HD
DTS:X
DTS Virtual:X
DTS Neural:X upmixing
DTS Decoder: DTS:X, DTS-HD Master Audio
CinemaFILTER
AccuEQ Room Calibration
Direct/Pure Mode
Advanced Music Optimizer
384K/32 Bit DACs

CONNECTIVITY
Analog Audio IN: 3
Digital Audio IN (OPT/COAX): 1 / 1
USB Input
HDMI I/O: 4 / 1
HDMI 4K/60 Hz- Capable HDMI Terminals
HDCP 2.3 Copy-Protection Compatibility (Enabled with a future firmware update)
HDMI Support for High Dynamic Range
HDMI Support for 3D, Audio Return Channel and CEC
BT.2020 Support
HDMI Support for Deep Color, x.v.Color, LipSync
HDMI Support for DVD-Audio, SACD, Multichannel PCM
1080p to 4K Upscaling
4K Passthrough
Analog Pre-Outs: Dual Subwoofer
Powered Zone 2
Zone B Line Out
Bluetooth: Version 4.2, Profile: A2DP 1.3, AVRCP 1.5

OTHER
Hybrid Standby Function
Auto Speaker Calibration W/Mic.: AccuEQ
OSD Out
Warranty: 2 YEARS
Power Supply: AC 120 V~, 60 Hz
Power Consumption: 445 W
Standby Power Consumption: 0.1 W
Dimensions (W x H x D) 17 1/8" x 6 5/8" x 12 15/16" (435 x 160 x 328 mm)
Weight: 18.1 lbs (8.2 kg)
Video: 1.0 Vp–p ±5% / 75 Ohms (Composite)
FM: 87.5 MHz–107.9 MHz
AM: 530 kHz–1,710 kHz
FM/AM Preset Memory: 40 stations
